Restoration tips and parts suppliers
Sometimes you just have to get by with a little help
Click on images to enlarge
Chassis . . . . . . Torsion Bars . . . . . . 392 Hemi
Lube chart, carter sticker & 2 Carter C2651S images
My air cleaner and my brake booster and vacuum tank
The brake master cylinder, carb close up and the whole engine bay
The position of the oil filter makes access lots of fun for the contortionist
These cars, like any other forty year old car, have their challenges. A Factory Service Manual is an absolute must. Getting parts for them, thanks to the internet, is not as hard as you might think. All in all, except for absolutely standard items, local parts stores are not very good. NAPA does not even include the 392 Hemi on its computer system. Autozone does, but can rarely get the parts they list. Air cleaners, oil filters, are all special order items. I have, over the years, come across some reasonable ways to overcome the difficulties and will do my best to share what I know with you. Please use the response page to write to me about a specific issue if it is not covered here.
Replacing a rear wheel brake cylinder
Click below for text and pictures that describe the task in detail
•Replacing a rear wheel cylinder•
Here is a small list of suppliers that I have used.
Power Play Hemi, AKA 'Hot Heads' http://www.powerplayhemi.com
This place is the best place I have yet found for parts for the Hemi. I have purchased a replacement Head, intake and exhaust valves, the valve seats, a complete gasket set and the special plug wires. I have found them to be friendly, knowledgeable, expedient and reasonable.
Andy Bernbaums http://www.oldmoparts.com
Bernbaums provide a catalog. They do a nice line in brakes, wheel cylinder, rubber parts and a hundred and other smaller trim items. Definitely a good place to start. My dealings with them have been very fair and fast.
Karps http://www.resleeve.com
Karps is the only place in the world making new brake booster sleeves for this era of Mopar. Their product is fabulous and very reasonably priced. They can supply with the concertina style rubber by itself, or you can ship your entire bellows unit to them and they will fit it for you.
Dr. Mopar http://www.drmopar.com/
Dr. Mopar has a scrap yard devoted exclusively to Mopar product. He even has two 1958 Imperials. He does most of his business over the internet. He is located in between San Marcos and Bastrop, Texas.
Wildcat Auto Wrecking http://www.wildcatmopars.com/
Wildcat provides excellent service. Another very good place to start.
Quality Engineered Products.
PO BOX 548, W. Linn, OR 97068. (503) 656-4545
Not sure if this guy has a web site or not, but he makes some very useful stuff. You can no longer get a mechanical fuel pump for a 392. But with a clever little spacer this guy sells, you can fit an absolutely standard Dodge mechanical pump straight of the shelf. Lovely!
Here is a miscellaneous parts list, and their numbers.
Air Filter - NAPA 2030
Brake Cylinder (Rear wheels) - NAPA 32555
Brake Light Switch - NAPA SL136 (This is correct only up to a point. There may be an absolutely correct part available. This part will work very well, but will need an adaptor. The part has a 1/8 inch pipe thread and the bottom of the master cylinder is 1/4 inch. However, an adaptor is readily available, and barely affects appearance. All you will see is an additional 5/8 inch hexagonal nut. A very small proce to pay for being able to get the part off the shelf.)
Carburetor C2650 & C2651s rebuild kit - 96-113D (GP Sorensen)
Lower main radiator hose - 3729
Oil Filter - NAPA Gold 1080
Power Steering Pump Belt - KS 15420
Spark plug - AC Delco R44 XLS
Temperature Sending Unit - Eichlin TS 6460
Thermostat - NAPA 191
More Stuff Coming Soon
