Move your way through the 1949 Chrysler Reference & Service Guide On How To Adjust The Rear Axle by choosing your next page. You are currently on Page 29.
Front Cover Page 2 - Introduction & An Overview Of How Servicing The Rear Axle Page 3 - The Two Ways To Adjust The Gear & Pinion Page 4 - Inspect All New Parts Before Installing Them Page 5 - More On What To Check Before Installing The New Pinion Page 6 - Assembly - Button Up The Differential Unit First Page 7 - Assembly - Differential Bearing Installation Page 8 - The 4 Steps In Ring Gear & Pinion Adjustment Page 9 - How Pinion Bearings Are Preloaded Page 10 - An Inside Look At Pinion Bearing Preload Page 11 - When Preload Lacks Some Oomph Page 12 - When Preload Is On Its Muscle Page 13 - What About The Pinion Oil Seal Page 14 - How To Set The Pinion Properly Page 15 - More On Properly Setting The Pinion Page 16 - How Differential Bearings Are Preloaded Page 17 - Killing Two Birds With One Stone Page 18 - More On Adjusting The Ring Gear Backlash Page 19 - Tightening The Back-Face Adjuster & Tooth-Side Adjuster Page 20 - More On Adjusting The Tooth-Side Adjuster Page 21 - Tooth-Side Adjuster Wear Patterns And What They Mean Page 22 - Heavy Toe Contact & Heavy Heel Contact Wear Page 23 - Good Tooth Contact Is Worth Obtaining Page 24 - Installing The Pinion Oil Seal Page 25 - Using The Gauge To Install The Bearing Page 26 - Preload Pinion Bearings First Page 27 - Finding The Pinion Setting Page 28 - When The Pinion's Marked Plus Or Minus Page 29 - More On Pinion Markings Page 30 - Differential Preload & Backlash Are The Same Page 31 - Remember To Check Axle Shaft End-Play Page 32 - How To Check & Control End-Play Page 33 - New Seals & Gaskets; What To Look For In The Final Road Test Page 34 - Inch-Pound Versus Foot-Pound & Bearing Preload Page 35 - Rear Axle Repair Glossary Back Cover Including Test Questions
Go back to Page 28 Go on to Page 30
Close this window to return to 1949 Rear Axle Adjustment's Table of Contents.
We also have a much larger, printable version of this page available. This booklet was originally a tiny 5" x 7".
